Providing illumination in public spaces, promoting safety and security, and enabling various outdoor activities at night. An auto on and off lighting shall enhance life of a street lamps.
Product Advantages
- Integrated design, modular production and one screw installation.
- With PC outdoor optical lens, high light transmittance, High temperature resistance and aging resistance.
- With LifePO4 battery, high safety, long lifespan.
- With high efficiency LED 50000 hours lifespan.
- Low voltage design, safe and reliable.
- Full night lighting.
- The light can be installed from equator area to Polar Regions.
- 8 to 10 years Lifespan.
Product Parameters
| Solar Module |
|---|
|
Maximum Power (Pmax) - 120W Voltage at Max (Vmp) - 5V Current at Max (Imp) - 19A Circuit Voltage (Voc) - 6.28V Short Short Circuit Current (Isc) - 21.16A Solar Panel Efficiency - More than 19% |
| LED |
|---|
|
More than 5000 hours of Lifespan Installation Height - 6 to 8 meters Installation Distance - 30 to 35 meters Built with PMMA Cover, 93% Light transmittance Intelligent Power Control Lumens - 5000 |
| Lithium PO4 Battery |
|---|
|
Battery - 3.2V-160Ah LifePO4 Nominal Voltage - 3.5V, Stored Energy - 208Wh 3000 cycles at 100% DoD, 5000 cycles at 80% DoD 98% energy efficiency Optimum temperature in charge - 40C to +70C Optimum temperature in discharge - 15C to +60C High safety with advanced Built-in Battery Management System Monitoring of cell and PCB temperature, current, voltage, cell balancing etc. 100% maintenance free |
